FEATURES AND ADVANTAGES
1. Easy to use with LCD screen display；
2. Charge and discharge time and power can be programmed；
3. Wide range of PV input voltage；
4. Smart BMS which ensures battery safety, 0 after-sales problems；
5. Integrate backup fuctions；
6. This is an Integrated energy storage systems including a hybrid inverter and lithium batteries(1-6 piece)；
7. This model realizes line pre-installation and factory testing to ensure fast installation；
8. Uses top brand cells, such as BYD, REPT,EVE etc, and supports appointed brand；
PRODUCT PARAMETERS
| Rated energy capacity | 5kwh |
| Battery type | LiFePO4 |
| Cycle | >6000 cycles (80%DOD, 25℃ |
| Battery working voltage | 44.8-58.4v |
| Working temperature | Charging: 0~45℃ Discharging: -30~55℃ |
| Charging current | 100A |
| Packge size | 930 x 598 x 275mm |
| Product size | 500 x 185 x 834mm |
| weight | 65kg |
| Communication port | USB/RS485/WIFI/ Bluetooth(optional) |
| Safety certificate | CE, RCM, UN38.3, Test report, IEC62619 |
48V/51.2V 100/200/300ah split wall-mounted battery for household
1. Cycles life>6000 times, supports calender life>10 years
2. With 100AMP smart BMS, that prevent over-voltage, under voltage, charge- discharge
3. Support canbus/RS485 communication and mainstream inverters
4. Up to16pcs connecting in parallel
5. Uses top brand cells, such as BYD, REPT,EVE etc, and supports appointed brand；
View moreBMS SYSTEM
For battery group anD single series cells, it provides hardware and software protection functions such as over-voltage, under voltage, charge- discharge, over - current, high - low temperature ans short circuit, etc.
The system terminal receives SOC and SOH information through: RS485-1 and RS485-2 interfaces.
It can calculate the present battery capacity by real - time montoring of the voltage and current; make relevant control and protection actions by monitoring various protection states and has intelligent cellegualization function to improve the battery pack's effective use time and cycle life.
PRODUCTION LINE
LeapPower has 50,000 square meters, fully equipped IS09001 factory, innovation research and development investment of 11.5%, with 4 production bases ans 4 R&D centers evenly distributed in Dongguan, Shenzhen and other places.
In the process of production, we always uphold a rigorous and serious working attitude, strictly control every part, and strive to produce high-quality products.
